Immersive Virtual Reality
Better design understanding and communication throughout the product development process.

NX Virtual Reality

NX Virtual Reality enables NX users to review their designs at human scale, giving you the ability to get up close and personal with full size models. NX Virtual Reality is integrated into the desktop application and accessible with one click, extending familiar interactions into a truly immersive 3D environment. Secure, multi-user sessions, facilitate collaboration across a whole range of key stakeholders, resulting in better design understanding and communication throughout the product development process.

Header Image_tcm27-78613.jpg

Extend familiar interactions into a truly immersive 3D environment


Support for multi-user VR sessions, combined with spatial audio integration takes design review participants to the next level of immersion. The hosts can collaborate with multiple users across different geographical locations allowing teams to save time and travel costs, whilst developing a shared understanding of designs and enabling faster iteration cycles.

Familiar Tools_Web_tcm27-89190.png

Familiar Inspection and Review Tools

Users can choose from a selection of familiar inspection tools including section, measure and paint. By leveraging the digital thread, you can also access detailed part information connected to your managed engineering data. The powerful section plane and capping tool enables interior inspection while the mark-up and snapshot features allow notes from a review session to be recorded and replayed.

One-click to VR

Unlike other VR apps which are a dead-end for your data, NX Virtual Reality is fully integrated into NX and leverages your managed engineering data and maintains the digital thread. NX Virtual Reality is accessible in one-click with no data preparation or time-consuming exports required. This integrated workflow saves you time and effort enabling your teams to focus on value added activities.

One Click to VR_Web_tcm27-89191.png
Human Scale_Web_tcm27-89192.png

Work at Human Scale

There’s a range of tools and features available which make the transition from the traditional 2D world, through to an immersive 3D experience as seamless as possible. Users can access dynamic controller tooltips for quick and easy guidance, whilst selecting and isolating part properties to truly understand the complexities of a full-scale model. Equipped with specialized navigational controls helps anyone, irrespective of experience in VR environments, to navigate around the scene with ease, resulting in highly effective design reviews.

Matt Godo explains how virtual reality in STAR-CCM+ allows anyone to explore a simulation model in an intuitive and immersive sense, increasing insight, and empowering innovation.

Interested in mechanical design with AR or VR?

Get more information Contact us.

Thank you, we will be in touch.

Accelerate time to market with 3D visualization

View, analyze and markup any BOM, in any configuration

Easily dive into 3D product data while viewing the bill of materials (BOM). Utilize an easy-to-use, intuitive set of DMU features to view, analyze and markup 3D data. Collaborate with your colleagues using 3D snapshots that accurately capture BOM context and 3D view information that can interchange between CAD and visualization applications.


Experience the digital twin, connected to Teamcenter

Experience your 3D JT models in a virtual, fully-immersive environment. Teamcenter VR supports interactivity and multi-user conferencing is compatible with most off-the-shelf VR devices and loads files with just one click. It also supports advanced functionalities such as path planning, interference and clearance analyses, and ergonomic assessment.

Visualize and interrogate any 3D JT file – fast

Simplify file sharing and shorten review cycles with JT2Go, a free viewing application that allows users to quickly load, view and interrogate 3D JT files of any size. With JT2Go, you can visualize product structures and product manufacturing information (PMI), including model views, cross-sections, and even CAE results. Users can also create/view snapshots and share files with other users.






Recreational vehicle manufacturer digitalizes concept of camper van

Company: Hymer

Industry: Automotive & Transportation

Location: Bad Waldsee, Germany

Siemens Software: Solid Edge, Teamcenter
